System Parameters
| Card Reading Frequency | 13.56MHz |
| 1:N Face Recognition Duration | ≤ 1 s/Person |
| Operation System | Linux |
| Fingerprint Module | Optical, Red Backlight |
| Card Capacity | 5,000 |
| Face Recognition Accuracy Rate | ≥ 99>#/td### |
| Card Type | Mifare Card |
| Camera | 0.3 MP Wide-Angle |
| Fingerprint Capacity | 5,000 |
| Event Capacity | 100,000 |
| Face Recognition Distance | 0.3 m to 1 m |
| Face Capacity | 2,000 |
Device Interfaces
| Communication Mode | Ethernet 10/100Mbps Self-adaptive; Wi-Fi |
| Output Interface | Doorbell × 1, Lock × 1, Alarm Output × 1 |
| Input Interface | RS-485 × 1, Wiegand × 1, Door Magnetic Sensor × 1, Exit Button × 1, Tamper × 1, Alarm Input × 2 |
| USB Interface | USB2.0 |
General
| LCD Screen | 5-inch LCD Touch Screen; Resolution: 800 × 480 |
| Lithium Battery | Lithium Battery Capacity: 3400 mAh |
| Power Supply | 12 VDC/2 A |
| Installation | Base Mounting; Wall Mounting |
| Application Situation | Indoor |
| Working Humidity | 10% to 90% (Non-Condensing) |
| Working Temperature | -10°C to +50°C (14°F to +122°F) |
| Dimensions (L×W×H) | 190mm × 157mm × 98mm (7.48” × 3.86” × 6.18″) |
