Video / audio input
| Video compression format | H.264 + / H.264 |
| IP cameras | 32 channels |
| Audio input | 1 channel, RCA (2.0 Vp-p, 1 kΩ) |
| Incoming bandwidth | 160 Mb / s |
| Outgoing bandwidth | 80 Mb / s |
Video / Audio Out
| Video output | 1 HDMI, 1 VGA |
| Output resolution | HDMI / VGA: 1920×1080 / 60Hz, 1280×1024 / 60Hz, 1280×720 / 60Hz, 1024×768 / 60Hz |
| Audio output | 1 channel, RCA (Linear, 1 KΩ) |
Record
| Number of threads | 2 |
| Main stream | 6MP / 5MP / 4MP / 3MP / 1080p / 1.3Mp / UXGA / 720p / VGA / 4CIF / DCIF / 2CIF / CIF / QCIF, 1/16 fps ~ 50k / s |
| Additional stream | VGA / 4CIF / CIF / QVGA, 1/16 fps ~ 25k / s |
| Stream type | Video, video and audio |
| Synchronous playback | 6 channels @ 1080P, 12 channels @ 720P |
Net
| Remote connections | 128 |
| Protocols | TCP / IP, DHCP, DNS, DDNS, NTP, UPnP ™, SADP, HIK Cloud P2P |
HDD
| SATA | 2 SATA |
| Volume | up to 6 TB each |
Interfaces
| Network interface | 1 RJ-45 10M / 100M / 1000M Ethernet |
| USB interface | 1 USB 2.0 1 USB 3.0 |
| Alarm In / Out | 4/1 |
General
| Nutrition | DC12V |
| Power consumption | Up to 10W (without HDD) |
| Working conditions | -10 ° C— + 55 ° C, humidity 10% ~ 90>#/td### |
| Weight | ≤1 kg (without HDD) |
