- System parameters
- Operation systemLinux
- ROM1 GB
- RAM4 GB
- ProcessorEmbeded high performance processor
- Display parameters
- Screen size4.3-inch
- Operation method/
- TypeColorful LCD
- Resolution800 × 480
- Video parameters
- Lens2 MP HD camera
- Resolution
Main stream: 1080p@30fps, 720p@30fps
Sub stream: VGA@25fps, VGA@30fps
- FOV/
- Wide dynamic range (WDR)Digital WDR/120 dB
- Supplement lightIR light, up to 3 m
- Video compression standardH.264; h.265; MJPEG
- Audio parameters
- Audio input1 built-in omnidirectional microphone
- Audio compression standardG.711 U、G.711 A、Opus、AAC-LD、AAC-LC、G.726、G.722.1
- Audio output1 built-in loudspeaker
- Audio compression bitrate64 Kbps
- Audio qualityNoise suppression and echo cancellation
- Volume adjustmentAdjustable
- Capacity
- User capacity10,000
- Face capacity5,000
- Card capacity50,000
- Network parameters
- Network protocolTCP/IP, RTSP, ipv6、onvif
- Wi-Fi/
- Bluetooth/
- 3G/4G/
- Device interfaces
- Alarm input4
- Network interface1 RJ-45 10/100/1000 Mbps self-adaptive
- TAMPER1
- Exit button1
- RS-4852 RS-485 (Half duplex, HIKVISION)
- USB/
- Wiegand/
- TF card/
- Alarm output/
- Lock control2 relays, Max. 30 VDC, 2 A
- Door contact input1
- General
- ButtonPhysical buttons
- >span class=”tech-specs-items-description__title-details”>Flush mounting
- Indicator/
- WeightNet weight: 1.186 kg Gross weight: 1.471 kg
- Protective levelIP65
- Working temperature-30 °C to 60 °C (-22 °F to 140 °F)
- Working humidity10% to 90% (no-condensing)
- Dimension (W × H × D)373 mm × 124 mm × 43.7 mm (14.69″ × 4.88″ × 1.72″)
- Power supply12 VDC, 1.5 A
- Application environmentOutdoor
- Power consumption≤ 13 W
- LanguageEnglish, Arabic, European French, Russian, European Spanish, Latin American Spanish, Italian, German, Polish, Turkish, Portuguese, Brazilian Portuguese, Uzbek, Kazakh, Czech, Hungarian, Dutch, Romanian, Bulgarian, Ukrainian, Croatian, Serbian, Greek, Lithuanian, Estonian, Latvian, Norwegian, Danish, Slovenian, Slovak, Hebrew, Swedish, Finnish, Mongolian, Vietnamese, Traditional Chinese (Taiwan), Latin American Spanish
