- Product Model
- Product ModelDS-D5B75RB/FL
- Display
- Screen Size75 inch
- BacklightDLED
- Pixel Pitch0.143 (H) mm × 0.430 (V) mm
- Resolution3840 × 2160 @60 Hz
- Brightness400 cd/m² (Typ.)
- Color Depth8 bit + RFC
- Display Color1.07 G
- Response Time5 ms
- Panel TypeIPS
- Contrast Ratio
1200:1 (Static)
15,000:1 (Dynamic)
- Color Gamut72% NTSC (CIE1931) (Typ.)
- Refresh Rate60 Hz
- Viewing Angle178°(H)/178°(V)
- Aspect Ratio16:9
- Surface Haze25% Haze
- Display Area1649.66 mm × 927.94 mm
- Working Duration7 × 16 H
- Surface Hardness
9H (Pencil)
7 (Mohs)
- Surface Glass3.2 mm Anti-Glare Glass
- Transmittance≥88>#/span###
- Lifespan50,000 hours
- Touch
- TypeInfrared Touch Screen
- Touch Point40-point multi-touch
- Touch Response Time＜ 5 ms
- Minimum Touch Object≥ 2 mm (≥ 90% touching area)
- Touch Precision± 1 mm (≥ 90% touching area)
- Touch Resolution32767 × 32767
- Built-in System
- Operation SystemAndroid 13.0
- Memory8 GB
- Built-in Storage128 GB
- CPUCortex-A55 × 4 (1.92 GHz)
- HDCP VersionSupport 1.4/2.2/2.3
- GPUMali-G52 MP2 (2EE)
- Camera
- Pixel
Up to 48 MP for Photos (Android)
Up to 8 MP for Video (Windows)
Up to 2 MP for Video (Android)
- Camera FunctionSupports intelligent switching between Android system, OPS, and PC.
- Field Angle93.4° (diagonal), 84.5° (horizontal), 54.1° (vertical)
- Distortion≤ 2.5>#/span###
- Camera Resolution RatioUp to 4K
- Microphone
- SpecificationOmni-directional 8-array layout
- Mic FunctionEcho reduction and smart noise-cancellation
- Voice Distance12 m
- Sampling Rate32 K
- Mic Depth16 bit
- Internal Function
- LoudspeakerBuilt-in 2 × 20 W
- Speaker Frequency200-20Khz
- BluetoothBuilt-in BLE (Bluetooth Low Energy) module supports Bluetooth 5.2
- NFCSupport card reader
- Light SensorYes
- Interface
- Video & Audio InputHDMI In (HDMI 2.0) × 2, Audio In × 1
- Video & Audio OutputAudio Out × 1
- Control InterfaceTOUCH-USB 2.0 × 1, RS232 × 1
- Network Interface
LAN (100 Mbps) × 2
Wi-Fi AP&Station, 2.4G/5G
Wi-Fi AP: IEEE 802.11 a/b/g/n/ac 2 × 2 MIMO (2.4 GHz and 5 GHz) authentication protocols WEP, WPA, WPA2, PSK and 802.1X EAP
Wi-Fi Station: IEEE 802.11 a/b/g/n/ac/ax 1 × 1 MIMO (2.4 GHz and 5 GHz) authentication protocols WEP, WPA, WPA2, PSK and 802.1X EAP
- Data Transmission InterfaceUSB 3.0 × 3, USB 2.0 × 2, Type-C × 1 (Type-C supports USB 2.0)
- Power
- Power Supply100 to 240 VAC, 50/60 Hz
- Standby Consumption≤ 0.5 W
- Max. Consumption217 W
- Average Consumption175 W
- Working Environment
- Working Temperature0 °C to 40 °C (32 °F to 104°F)
- Working Humidity10%~90% RH
- General
- Package Dimensions (W × H × D)1907 mm × 1160 mm × 223 mm
- VESA800 mm × 400 mm (4 × M8-25 mm)
- Net Weight46.26 kg
- Gross Weight62.99 kg
- AccessaryWall mount bracket, hook, user manual, stylus × 2, packing list, 1.5 m power cable (European standard), remote controller
- Product Dimensions （With Wall Attachment）1713.23 mm × 1038.54 mm × 111.9 mm
- Product Dimensions （Without Wall Attachment）1713.23 mm × 1038.54 mm × 82.5 mm
