Camera Specifications
- Sensor: 1/3″ Progressive Scan CMOS
- Max Resolution: 2560 × 1440
- Electronic Shutter Speed: From 1/3 to 1/100,000 s
- Sensitivity: Color: 0.005 Lux @ (F1.6, AGC on), B/W: 0 Lux with IR illumination
- Day/Night Mode: IR filter
- Angle Adjustment:
- Pan: 0 to 355°
- Tilt: 0 to 75°
- Rotation: 0 to 355°
Lens
- Lens Type: Fixed lens (2.8 and 4 mm optional)
- Focal Length and Field of View:
- 2.8 mm: Horizontal: 98°, Vertical: 54°, Diagonal: 114°
- 4 mm: Horizontal: 78°, Vertical: 42°, Diagonal: 93°
- Lens Mount: M12
- Aperture: F1.6
DORI
- 2.8 mm:
- Detection: 63 m
- Observation: 25 m
- Recognition: 12 m
- Identification: 6 m
- 4 mm:
- Detection: 78 m
- Observation: 31 m
- Recognition: 15 m
- Identification: 7 m
Illumination
- Illumination Type: IR and white light
- Illumination Range:
- IR: Up to 30 m
- White light: Up to 20 m
- Intelligent Illumination: Yes
- Infrared Wavelength: 850 nm
Video
- Main Stream:
- 50 Hz: 20 fps (2560 × 1440), 25 fps (1920 × 1080, 1280 × 720)
- 60 Hz: 20 fps (2560 × 1440), 24 fps (1920 × 1080, 1280 × 720)
- Sub Stream:
- 50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360)
- 60 Hz: 24 fps (1280 × 720, 640 × 480, 640 × 360)
- Video Compression:
- Main Stream: H.265+/H.265/H.264+/H.264
- Sub Stream: H.265/H.264/MJPEG
- Video Bitrate: From 32 kbps to 8 Mbps
- H.264 Profile: Baseline/Main/High
- H.265 Profile: Main
- Bitrate Mode: CBR, VBR
- Region of Interest (ROI): 1 fixed area for main stream
Audio
- Audio Type: Mono
- Noise Filtering: Yes
- Sampling Rate: 8/16 kHz
- Audio Compression: G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/AAC-LC
- Audio Bitrate:
- 64 kbps (G.711ulaw)
- 64 kbps (G.711alaw)
- 16 kbps (G.722.1)
- 16 kbps (G.726)
- From 32 to 160 kbps (MP2L2)
- From 16 to 64 kbps (AAC-LC)
Network
- Security: Password protection, complex password, watermarks, basic and digest authentication for HTTP, WSSE, and digest authentication for open network video interface, security log, host authentication (MAC address)
- Simultaneous Live View: Up to 6 channels
- API: Open Network Video Interface (Profile S, T, G), ISAPI, SDK
- Protocols: TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6, UDP, QoS, FTP, SMTP
- User/Host: Up to 32 users; 3 user levels: admin, operator, user
- Client Software: iVMS-4200, Hik-Connect
- Web Interface: Requires plugin for live view: IE 10, IE 11; Local services: Chrome 57.0+, Firefox 52.0+
- Wide Dynamic Range (WDR): 120 dB
- SNR: ≥ 52 dB
- Day/Night Mode Switching: Day/Night/Automatic/Scheduled
- Image Enhancement: BLC, HLC, 3D DNR
- Image Settings: Corridor mode, saturation, brightness, contrast, sharpness, gain, and white balance adjustable via client software or web interface
- Privacy Masking: 4 customizable polygonal masks
Interfaces
- Ethernet Interface: 1 RJ45 auto 10/100 M Ethernet
- Local Storage: Built-in microSD/microSDHC/microSDXC slot, up to 256 GB
- Built-in Microphone: Yes
- Reset Button: Yes
Events
- Main Events: Alarm trigger for various object types (human, vehicle), tamper detection, exclusion
- Linkage: Upload to FTP/memory card, send email, notification to monitoring center, alarm recording, image capture
Power Supply
- Power Requirements: DC 12 V ± 25%, 0.5 A, max. 6 W, coaxial power connector Ø 5.5 mm, reverse polarity protection, PoE: IEEE 802.3af, class 3, max. 7.5 W
Physical
- Material: Metal and plastic
- Dimensions: Ø 121.4 × 97.7 mm (Ø 4.8 × 3.8″)
- Packaging Size: 150 × 150 × 141 mm (5.9 × 5.9 × 5.6″)
- Weight: Approx. 550 g
- Weight with Packaging: Approx. 800 g
Storage Conditions
- Temperature: -30 to +60 °C, Humidity 95% or less (no condensation)
- Operating Conditions: -40 to +60 °C, Humidity: 95% or less (no condensation)
- Language: English, Ukrainian
Main Features
- Heartbeat, Anti-banding, Mirroring, Password protection, Password change via email
Certifications
- EMC Standards: FCC: 47 CFR Part 15, Subpart B; CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013 + A1:2019, EN 50130-4: 2011 +A1: 2014, RCM: AS/NZS CISPR 32: 2015, IC: ICES-003: Issue 7
- Safety Standards: UL: UL 62368-1; CB: IEC 62368-1: 2014 + A11; CE-LVD: EN 62368-1: 2014 / A11: 2017; BIS: IS 13252 (Part 1): 2010 / IEC 60950-1: 2005
- Environmental: CE-RoHS: 2011/65/EU; WEEE: 2012/19/EU; REACH: Regulation (EC) No 1907/2006
- Protection Standards: IP67: IEC 60529-2013; IK08: IEC 62262:2002
Camera Specifications
- Sensor: 1/3″ Progressive Scan CMOS
- Maximum Resolution: 2560 × 1440
- Electronic Shutter Speed: From 1/3 to 1/100000 s
- Sensitivity: Color: 0.005 Lux @ (F1.6, AGC on), B/W: 0 Lux with IR illumination
- Day/Night Mode: IR filter
- Angle Adjustment: Pan: 0 to 355°; Tilt: 0 to 75°; Rotation: 0 to 355°
Lens
- Lens Type: Fixed lens, 2.8 and 4 mm (optional)
- Focal Length and Viewing Angle:
- 2.8 mm: Horizontal: 98°, Vertical: 54°, Diagonal: 114°
- 4 mm: Horizontal: 78°, Vertical: 42°, Diagonal: 93°
- Lens Mount: M12
- Aperture Type: Fixed
- Aperture: F1.6
DORI
- DORI for 2.8 mm: Detection: 63 m, Observation: 25 m, Recognition: 12 m, Identification: 6 m
- DORI for 4 mm: Detection: 78 m, Observation: 31 m, Recognition: 15 m, Identification: 7 m
Illumination
- Illumination Type: IR illumination and white light
- Illumination Range:
- IR illumination: up to 30 m
- White light: up to 20 m
- Intelligent Illumination: Yes
- Infrared Wavelength: 850 nm
Video
- Main Stream:
- 50 Hz: 20 fps (2560 × 1440), 25 fps (1920 × 1080, 1280 × 720)
- 60 Hz: 20 fps (2560 × 1440), 24 fps (1920 × 1080, 1280 × 720)
- Secondary Stream:
- 50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360)
- 60 Hz: 24 fps (1280 × 720, 640 × 480, 640 × 360)
- Video Compression:
- Main stream: H.265+ / H.265 / H.264+ / H.264
- Secondary stream: H.265 / H.264 / MJPEG
- Video Bitrate: From 32 Kbps to 8 Mbps
- H.264 Profile: Baseline Profile/Main Profile/High Profile
- H.265 Profile: Main Profile
- Bitrate Mode: CBR, VBR
- Region of Interest (ROI): 1 fixed area for the main stream
Audio
- Audio Type: Mono
- Noise Filtering: Yes
- Sampling Frequency: 8/16 kHz
- Audio Compression: G.711ulaw / G.711alaw / G.722.1 / G.726 / MP2L2 / PCM / AAC-LC
- Audio Bitrate:
- 64 Kbps (G.711 ulaw)
- 64 Kbps (G.711 alaw)
- 16 Kbps (G.722.1)
- 16 Kbps (G.726)
- From 32 to 160 Kbps (MP2L2)
- From 16 to 64 Kbps (AAC-LC)
Network
- Security: Password protection, complex passwords, watermarks, basic and digest authentication for HTTP, WSSE and digest authentication for ONVIF, security log, host authentication (MAC address)
- Simultaneous Live Viewing: Up to 6 channels
- API: Open Network Video Interface (Profile S, Profile T, Profile G), ISAPI, SDK
- Protocols: TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6, UDP, QoS, FTP, SMTP
- User/Host: Up to 32 users with 3 user levels: administrator, operator, and user
- Client Software: iVMS-4200, Hik-Connect
- Web Interface: Requires plugin for real-time viewing: IE 10, IE 11; Local services: Chrome 57.0+, Firefox 52.0+
- Wide Dynamic Range (WDR): 120 dB
- SNR: ≥ 52 dB
- Day/Night Mode Switching: Day/Night/Automatic/Scheduled
- Image Enhancement: BLC, HLC, 3D DNR
- Image Settings: Corridor mode, adjustable saturation, brightness, contrast, sharpness, gain, and white balance via client software or web interface
- Privacy Masking: 4 customizable polygonal privacy masks
Interfaces
- Ethernet Interface: 1 RJ45 auto 10/100 Mbps Ethernet
- Local Storage: Built-in microSD card slot, supports microSD/microSDHC/microSDXC, up to 256 GB
- Built-in Microphone: Yes
- Reset Button: Yes
Events
- Main Events: Triggered alarm for various object types (person, vehicle), tamper detection, exclusion
- Actions: FTP upload/memory card, email sending, monitoring center notification, alarm recording, image capture
Power
- Power Supply: DC 12 V ± 25%, 0.5 A, max. 6 W, coaxial power connector Ø 5.5 mm, reverse polarity protection, PoE: IEEE 802.3af, class 3, max. 7.5 W
- Material: Metal and plastic
- Dimensions: Ø 121.4 × 97.7 mm (Ø 4.8 × 3.8″)
- Packaging Size: 150 × 150 × 141 mm (5.9 × 5.9 × 5.6″)
- Weight: Approx. 550 g
- Weight with Packaging: Approx. 800 g
- Storage Conditions: From -30 to +60 °C, humidity 95% or less (without condensation)
- Operating Conditions: From -40 to +60 °C, humidity 95% or less (without condensation)
- Languages: English, Ukrainian
- Main Features: Heartbeat, Anti-banding, mirroring, password protection, password change via email
Certifications
- EMC Standards: FCC: 47 CFR Part 15, Subpart B, CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013 + A1:2019, EN 50130-4: 2011 +A1: 2014, RCM: AS/NZS CISPR 32: 2015, IC: ICES-003: Issue 7
- Safety Standards: UL: UL 62368-1, CB: IEC 62368-1: 2014 + A11, CE-LVD: EN 62368-1: 2014 / A11: 2017, BIS: IS 13252 (Part 1): 2010 / IEC 60950-1: 2005
- Environmental Standards: CE-RoHS: 2011/65/EU, WEEE: 2012/19/EU, REACH: Regulation (EC) No 1907/2006
- Protection Standards: IP67: IEC 60529-2013, IK08: IEC 62262:2002
