- Camera
- Image Sensor1/3″ Progressive Scan CMOS
- Max. Resolution1920 × 1080
- Min. IlluminationColor: 0.01 Lux @ (F2.0, AGC ON),B/W: 0 Lux with IR
- Shutter Time1/3 s to 1/100,000 s
- Day & NightIR cut filter
- Angle AdjustmentPan: 0° to 360°,tilt: 0° to 90°,rotate: 0° to 360°
- Lens
- Lens TypeFixed focal lens, 2.8, 4, and 6 mm optional
- Focal Length & FOV
2.8 mm, horizontal FOV 101°, vertical FOV 56°, diagonal FOV 118°
4 mm, horizontal FOV 78°, vertical FOV 42°, diagonal FOV 92°
6 mm, horizontal FOV 49°, vertical FOV 28°, diagonal FOV 56°
- ApertureF2.0
- Iris TypeFixed
- Lens MountM12
- Depth of Field
2.8 mm: 0.8 m~∞
4 mm: 1.1 m~∞
6 mm: 2.3 m~∞
- DORI
- DORI
2.8 mm, D: 43 m, O: 17 m, R: 8 m, I: 4 m
4 mm, D: 59 m, O: 23 m, R: 11 m, I: 5 m
6 mm, D: 86 m, O: 34 m, R: 17 m, I: 8 m
- Illuminator
- Supplement Light TypeIR, White Light
- IR Wavelength850 nm
- Supplement Light RangeUp to 30 m
- Smart Supplement LightYes
- Video
- Main Stream
50 Hz: 25 fps (1920 × 1080, 1280 × 720, 768 x 432)
60 Hz: 30 fps (1920 × 1080, 1280 × 720, 768 x 432)
- Sub-Stream
50 Hz: 25 fps (768 × 432)
60 Hz: 30 fps (768 × 432)
- Video Compression
Main stream: H.265/H.264,
Sub-stream: H.265/H.264/MJPEG
- Video Bit Rate32 Kbps to 8 Mbps
- H.264 TypeBaseline Profile,Main Profile,High Profile
- H.265 TypeMain Profile
- Bit Rate ControlCBR,VBR
- Region of Interest (ROI)1 fixed region for main stream
- Audio
- Audio TypeMono sound
- Audio CompressionG.711(ulaw)/ (AAC-LC)
- Audio Bit Rate64 Kbps (G.711ulaw)/16 to 64 Kbps (AAC-LC)
- Audio Sampling Rate8 kHz/16 kHz
- Environment Noise FilteringYes
- Network
- SecurityPassword protection, complicated password, watermark, basic and digest authentication for HTTP, WSSE and digest authentication for Open Network Video Interface, security audit log, host authentication (MAC address)
- Simultaneous Live ViewUp to 6 channels
- APIONVIF (Profile S, Profile G, Profile T), ISAPI, SDK
- ProtocolsTCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTCP, RTSP, NTP, IGMP, IPv4, IPv6, UDP, QoS, UPnP
- User/Host
Up to 32 users
3 user levels: administrator, operator, and user
- Client
Wired network: Hik-Connect, iVMS-4200
Wi-Fi: iVMS-4200
*Wi-Fi connection with Hik-Connect directly is not possible
- Web BrowserLocal service: IE 11, Chrome 57.0+, Firefox 52.0+, Edge 89+
- Wi-Fi
- Frequency Range2.4 GHz to 2.4835 GHz
- Channel Bandwidth20/40 MHz
- Wi-Fi ProtocolIEEE802.11b,IEEE802.11g,IEEE802.11n,IEEE802.11ax
- Modulation
802.11b: DBPSK, DQPSK, CCK,
802.11g: BPSK, QPSK, 16QAM, 64QAM,
802.11n: BPSK, QPSK, 16QAM, 64QAM,
802.11ax: BPSK, QPSK, 16QAM, 64QAM, 256QAM
- Transfer Rate
11b: up to 11 Mbps,
11g: up to 54 Mbps,
11n: up to 150 Mbps,
11ax: up to 114 Mbps
- Image
- Wide Dynamic Range (WDR)Digital WDR
- SNR≥ 52 dB
- Day/Night SwitchDay, Night, Auto, Schedule
- Image EnhancementBLC, HLC, 3D DNR
- Image SettingsSaturation, brightness, contrast, sharpness, gain, white balance, adjustable by client software or web browser
- Privacy Mask4 programmable polygon privacy masks
- Interface
- On-Board StorageBuilt-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB
- Built-in MicrophoneYes
- Built-in SpeakerYes
- Reset KeyYes
- Ethernet Interface1 RJ45 10 M/100 M self-adaptive Ethernet port
- Event
- Basic EventMotion detection (support alarm triggering by specified target types (human and vehicle)),exception
- LinkageNotify surveillance center, send email, trigger recording, trigger capture, audible warning
- General
- Power12 VDC ± 25%, 0.55 A, max. 6.5 W,Ø5.5 mm coaxial power plug,reverse polarity protection,A switching adapter is included in the package.
- MaterialPlastic
- Dimension260.9 mm × 113.9 mm × 67.4 mm (10.3″ × 4.5″ × 2.7″)
- Package Dimension300 mm × 130 mm × 100 mm (10.2″ × 5.1″ × 4.9″)
- WeightApprox. 310 g (0.68 lb.)
- With Package WeightApprox. 550 g (1.12 lb.)
- Storage Conditions-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
- Startup and Operating Conditions-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
- LanguageEnglish, Ukrainian
- General FunctionHeartbeat, anti-banding, mirror, password protection
- Approval
- EMCCE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014
- RFCE-RED: EN 301489-1 V2.1.1(BT or 2.4G); EN 301489-17 V3.1.1 (BT or 2.4G); EN 300328 V2.1.1 (BT or 2.4G); EN 62311:2008 (BT or 2.4G)
- Safety
CB: IEC 62368-1: 2014+A11,
CE-LVD: EN 62368-1: 2014/A11: 2017
- Environment
CE-RoHS: 2011/65/EU,
WEEE: 2012/19/EU,
Reach: Regulation (EC) No 1907/2006
- ProtectionIP66: IEC 60529-2013
