- Camera
- Image Sensor1/1.8＂ progressive scan CMOS
- Max. Resolution2560 × 1440
- Min. Illuminationcolor: 0.001 Lux @ (F1.2, AGC ON), B/W: 0.0005 Lux @(F1.2，AGC ON), 0 Lux with IR
- Shutter Speed1/1 s to 1/30,000 s
- Day & NightICR
- Zoom16x digital
- Slow Shutteryes
- HLCyes
- 3D DNRyes
- Optical Zoom36x
- DORI
Detect (25 px/m): 2965.5 m
Observe (63 px/m): 1176.8 m
Recognize (125 px/m): 604.1 m
Identify (250 px/m): 302.1 m
- Lens
- Focal Length6.0 mm to 216 mm, 36× Optical
- FOV
Horizontal field of view: 56.6° to 1.7° (wide-tele),
Vertical field of view: 33.7° to 0.9° (wide-tele),
Diagonal field of view: 63.4° to 1.9° (wide-tele)
- FocusAuto,semi-auto,manual,rapid focus
- ApertureF1.2
- Zoom Speedapprox. 4.5 s
- PTZ
- Movement Range (Pan)360°
- Movement Range (Tilt)-20° to 90° (auto flip)
- Pan Speedpan speed: configurable from 0.1° to 300°/s; preset speed: 540°/s
- Tilt Speedtilt speed: configurable from 0.1° to 240°/s, preset speed 400°/s
- Proportional Panyes
- Presets300
- Preset Freezingyes
- Patrol Scan8 patrols, up to 32 presets for each patrol
- Pattern Scan4 pattern scans, record time over 10 minutes for each scan
- Park Actionpreset||pattern scan||patrol scan||auto scan||tilt scan||random scan||frame scan||panorama scan
- 3D Positioningyes
- PTZ Status Displayyes
- Scheduled Taskpreset||pattern scan||patrol scan||auto scan||tilt scan||random scan||frame scan||panorama scan||dome reboot||dome adjust||aux output
- Power-off Memoryyes
- Video
- Main Stream
50 Hz: 25 fps (2560×1440, 1920×1080, 1280×960, 1280×720)
60 Hz: 30 fps (2560×1440, 1920×1080, 1280×960, 1280×720)
- Sub-Stream
50 Hz: 25 fps (704 × 576, 640 × 480, 352 × 288)
60 Hz: 30 fps (704 × 480, 640 × 480, 352 × 240)
- Third Stream
- 50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288)
- 60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240)
- Video CompressionH.265||H.264||MJPEG
- Video Bit Rate32 Kbps to 16384 Kbps
- H.264 Typebaseline profile||main profile||high profile
- H.265 Typemain profile
- Scalable Video Coding (SVC)yes
- Region of Interest (ROI)fixed region
- Audio
- Audio CompressionG.711alaw||G.711ulaw||G.722.1||G.726||MP2L2||PCM
- Audio Bit Rate64 Kbps(G.711)/16 Kbps(G.722.1)/16 Kbps(G.726)/32~192 Kbps(MP2L2)
- Network
- ProtocolsIPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, DHCP, PPPoE, UDP, IGMP, ICMP, Bonjour
- Simultaneous Live ViewUp to 20 channels
- APIOpen-ended API|| ISAPI||Hikvision SDK||Third-party management platform||Ehome||ISUP||ONVIF (Profile S, Profile G, Profile T)
- Smooth Streamingyes
- User/HostUp to 32 users. 3 levels: Administrator, Operator and User
- SecurityUser authentication (ID and PW), Host authentication (MAC address); HTTPS encryption; IEEE 802.1x port-based network access control; IP address filtering
- Network StorageNAS (NFS, SMB/ CIFS)||ANR
- ClientiVMS-4200||Hik-Connect||Hikcentral
- Web BrowserIE11, Chrome 57.0+, Firefox 52.0+, Safari 11+
- Image
- Day/Night Switchday, night, auto, scheduled-switch
- Wide Dynamic Range (WDR)140 dB WDR
- SNR≥52dB
- Defogyes
- Image StabilizationEIS (Built-in gyroscope to improve EIS performance)
- Image EnhancementBLC, HLC, 3D DNR
- Privacy Maskup to 24 masks||polygon region ||mosaic mask ||mask color configurable
- Regional Focusyes
- Regional Exposureyes
- Interface
- Video Output1.0V[p-p]/75Ω||PAL||NTSC||BNC connector
- Ethernet InterfaceRJ45, self-adaptive 10M/100M Ethernet port
- On-board StorageBuilt-in memory card slot, support Micro SD/Micro SDHC/Micro SDXC, up to 256 GB; NAS (NFS, SMB/ CIFS), ANR
- Audio
1 input (line in), max. input amplitude: 2-2.4 vpp, input impedance: 1 KΩ ± 10%,
1 output (line out), line level, output impedance: 600 Ω
- Alarm7 alarm inputs, 2 alarm outputs
- RS-485HIKVISION, Pelco-P, Pelco-D, self-adaptive
- Event
- Basic Eventmotion detection||video tampering alarm||alarm input and output||exception
- Smart Eventintrusion detection||line crossing detection||region entrance detection||region exiting detection||parking detection||unattended baggage detection||object removal detection||vandal-proof alarm||audio exception detection
- LinkageAlarm actions, such as Preset, Patrol Scan, Pattern Scan, Memory Card Video Record, Trigger Recording, Notify Surveillance Center, Upload to FTP/Memory Card/NAS, Send Email, etc.
- Smart Trackingmanual tracking||event tracking||auto-tracking
- Deep Learning Function
- Face CaptureSupport detecting up to 30 faces at the same time. Support detecting, tracking, capturing, grading, selecting of face in motion, and output the best face picture of the face.
- Road TrafficSupport vehicle detection (license plate number,vehicle model, and vehicle color recognition)
- General
- Power24 VAC±25% (Max. 45 W, including max. 6 W for heater), Hi-PoE (Max. 50 W, including max. 6 W for heater)
- Dimension⌀ 231.1 mm × 355.6 mm (⌀ 9.10″ × 14″)
- WeightApprox. 6 kg (13.23 lb.)
- Operating ConditionTemperature: -40°C to 70°C (-40°F to 158°F)，Humidity: ≤ 95>#/span###
- General Functionmirror, password protection, watermark, IP address filter
- Language33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
- Approval
- EMC
FCC SDoC (47 CFR Part 15, Subpart B);
CE-EMC (EN 55032: 2015, EN 61000-3-2: 2019, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014);
RCM (AS/NZS CISPR 32: 2015);
IC VoC (ICES-003: Issue 6, 2019);
KC (KN 32: 2015, KN 35: 2015)
- Safety
UL (UL 62368-1)
CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014);
CE-LVD (EN 62368-1:2014+A11:2017),
BIS (IS 13252(Part 1):2010+A1:2013+A2:2015);
LOA (SANS IEC60950-1)
- Environment
CE-RoHS (2011/65/EU); WEEE (2012/19/EU);
Reach (Regulation (EC) No 1907/2006)
- ProtectionLightning Protection, Surge Protection and Voltage Transient Protection,±6kV Line to Gnd, ±3kV Line to Line,IEC61000-4-5||IP67 Standard||IK10
- Anti-Corrosion ProtectionNEMA 4X
