- Camera
- Image Sensor2 MP CMOS
- Signal SystemPAL/NTSC
- Max. Resolution1920 (H) × 1080 (V)
- Min. Illumination0.1 Lux @ (F1.2, AGC ON)
- Shutter TimePAL: 1/25 s to 1/50,000 s;NTSC: 1/30 s to 1/50,000 s
- Day & Night24/7 Color Imaging
- Angle Adjustmentpan: 360°; tilt: -15° to 15°; ratation: 0°
- Lens
- Lens Type3.6 mm fixed focal lens
- Focal Length & FOVhorizontal FOV: 86°, vertical FOV: 55°, diagonal FOV: 95°
- Lens MountM8
- Object Distance Range0.5 m to ∞
- Image
- Frame Rate
MJPG:
1920 × 1080 @ 30/25 fps
1280 × 960 @ 30/25 fps
1280 × 720 @ 30/25 fps
640 × 480 @ 30/25 fps
640 × 360 @ 30/25 fps
YUV:
1920 × 1080 @ 5 fps
1280 × 960 @ 5 fps
1280 × 720 @ 5 fps
640 × 480 @ 30 fps
640 × 360 @ 30 fps
- White BalanceAuto
- Audio
- Audio Sampling Rate16 kHz
- Interface
- Video OutputUSB 2.0
- AudioBuilt-in mic
- Indicator
Red: Standby
Blue: Normally Working
- General
- Operating Condition-10°C to 45°C, Humidity: 90% or less (non-condensing)
- MaterialPlastic
- Dimension80.16 mm × 48.6 mm × 42.18 mm (3.16″ × 1.91″ × 1.66″)
- WeightApprox. 89 g (0.2 lb.)
- Packing List
Camera × 1
Quick Start Guide × 1
- PowerDC 5V ± 5% (USB), Max. 1.2 W
- Cable Length1.5 m
- System Requirement
Recommended systems
Windows 7/8/10/11
Android 8.1 and above version
Linux 4.14 and above version
macOS 10.12 and above version
Chrome OS
