- Display
- Screen Size23.8 inch
- Active Display Area527.04 (H) mm × 296.46 (V) mm
- Resolution1920 × 1080
- BacklightE-LED
- Pixel Pitch0.2745 (H) mm × 0.2745 (V) mm
- Brightness250 cd/m²
- Viewing Angle178° (H) / 178° (V)
- Color Depth8 bit ,16.7 M
- Contrast Ratio4000 : 1
- Response Time7ms
- Refresh RateTyp. 60 Hz , Max. 100Hz
- HazeHaze 25>#/span###
- Reliability7 × 16 H
- Color Gamut72% NTSC
- Interface
- Video & Audio InputHDMI 1.4 × 1, VGA × 1
- Video & Audio OutputAudio Out × 1
- Data Transmission InterfaceNone
- Control InterfaceNone
- Power
- Power SupplyDC 12V, 2.0A
- Power Consumption≤ 24 W
- Standby Consumption≤ 0.5 W
- Working Environment
- Working Temperature0℃ to 40 ℃ (32 ℉ to 104 ℉)
- Working Humidity20% to 90% RH (Non-Condensing)
- Storage Temperature-20 ℃ to 60 ℃ (-4 ℉ to 140 ℉)
- Storage Humidity10% to 90% RH (Non-Condensing)
- General
- Casing MaterialPlastic
- VESA75 mm × 75 mm (4 – M4 × 6 mm)
- Bezel Width2.0 mm (top/left/right), 23.55 mm (bottom)
- Product Dimensions (W × H × D)
With base: 539.7 (W) mm × 427.33 (H) mm × 185.69(D) mm
21.25 (W) inch × 16.82 (H) inch × 7.31 (D) inch
Without base: 539.7 (W) mm × 327.33 (H) mm × 43.5 (D) mm
21.25 (W) inch × 12.89 (H) inch × 1.71 (D) inch
- Package Dimensions (W × H × D)
611 (W) mm × 405 (H) mm × 118 (D) mm
(24.06(W) × 15.94(H) × 4.65 (D) ) inch
- Net Weight2.85 ± 0.5 kg
- Gross Weight3.85± 0.5 kg
- Packing ListMonitor × 1, Base component × 1, Power adapter (12 V, 2 A) × 1, HDMI cable (1.5 m) × 1, User manual × 1, Multilingual manual × 1
- Remarks
The base is included by default.
The product appearance and parameters in this specification may vary from your actual device. Please consult our local sales staff for further information
