- Barrier Housing
- Barrier Housing MaterialCold-rolled sheet
- Barrier Housing Thickness1.2 mm
- Barrier Housing Door Thickness1.0 mm
- Barrier Housing ColorBlack background with sliver pattern
- Barrier Housing Door ColorBlack background with sliver pattern
- Boom Pole Installation Height880 mm
- Body IndicatorsNone
- Barrier Gate General
- Rising/Falling Speed
2m+2m folding pole ：
Rising Speed: 3 to 6 s
Falling Speed: 3 to 6 s
- Boom Pole DirectionLeft/Right
- Motor TypeDC brushless motor
- Matched Boom Pole TypeFolding boom pole
- Boom Pole Falling Delay1 to 99 s
- Number of Cycles2,500,000
- Consumption100 W
- Temperature and HumidityHumidity: ≤ 90
- Rising Boom Pole for PoweroffOptional
- Package
- Barrier Housing Dimensions (L × W × H)325 × 220 × 1000 mm (12.8 × 8.67 × 39.37 inch)
- Body Weight26 ± 0.2 kg (57.32 ± 0.44 lb.)
- Body Dimensions (with Package, Without Boom Pole) (L × W × H)385 × 305 × 1060 mm (15.16 × 12 × 41.73 inch)
- Body Weight (with Package, Without Boom Pole)29.1 ± 0.2 kg (64.15 ± 0.44 lb.)
- Interface
- RS-485Optional
- Rising to Limit1 group
- Falling to Limit1 group
- Open1 group
- Close1 group
- Stop1 group
- IR/Vehicle Detector/Radar1 group
- Traffic Signal Light1 group
- General
- Power Supply110-240VAC( default 220V，Switchable )
- Approval
- ProtectionIP54
- Boom Pole
- Boom Pole ColorWhite background with red bar
- Boom Pole Weight
2 m + 2 m folding boom pole: 6.7 ± 0.2 kg
1.5 m + 2.5 m folding boom pole: 6.4 ± 0.2 kg
- Boom Pole Dimensions (with Package)
2 m + 2 m folding boom pole: 2260 × 200 × 110 mm（L×W×H）
1.5 m + 2.5 m folding boom pole: 2750 × 200 × 110 mm（L×W×H）
- Boom Pole Weight (with Package)
2 m + 2 m folding boom pole: 7.7 ± 0.2 kg
1.5 m + 2.5 m folding boom pole: 7.3 ± 0.2 kg
- Boom Pole Dimensions
4038 × 75 × 190 mm（L×W×H）
- Boom Pole Material6063
