- General
- ShellMetal material, fan-free design
- Net Weight0.56 kg (1.23 lb)
- Gross Weight1.27 kg (2.79 lb)
- Dimensions (W × H × D)217.6 mm × 27.6 mm × 108.5 mm (8.57” × 1.09” × 4.27”)
- Operating Temperature0 °C to 40 °C (32 °F to 104 °F)
- Storage Temperature–40 °C to 85 °C (–40 °F to 185 °F)
- Operating Humidity5% to 95% (no condensation)
- Relative Humidity5% to 95% (no condensation)
- Power Supply54 VDC,2.22 A
- Max. Power Consumption120 W
- Power Consumption in Idle< 10 W
- >span class=”tech-specs-items-description__title-details”>Desk-Mounted
- Surge Protection6 KV
- Network Parameters
- Ports8 × 10/100 Mbps PoE port,2 × Gigabit RJ45 port
- MAC Address Table4 K
- Switching Capacity5.6 Gbps
- Packet Forwarding Rate4.17Mpps
- Internal Cache2Mbits
- PoE Power Supply
- PoE Standard
Ports 1 and 2: IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt
Ports 3 to 8: IEEE 802.3af, IEEE 802.3at
- PoE Power Pin
Ports 1 to 2: 8-pin power: 1/2(-), 3/6(+), 4/5(+), 7/8(-)
Ports 3 to 8: End-span: 1/2(-), 3/6(+)
- PoE Port
Hi-PoE: Ports 1 to 2
PoE: Ports 3 to 8
- Max. Port Power
Ports 1 and 2 : 90 W
Ports 3 to 8: 30 W
- PoE Power Budget110 W
- Dialing Function
- Long Range
Ports 1 to 8: up to 300 m.
Long range performance may vary depend on camera model or cable condition.
- Port IsolationPorts 1 to 8: port isolation mode to improve network security.
- PoE WatchdogPorts 1 to 8: auto detect and restart the cameras that do not respond.
- Approval
- EMCCE-EMC (EN 55032: 2015+A11: 2020, EN IEC 61000-3-2: 2019, EN 61000-3-3: 2013+A1: 2019, EN 50130-4: 2011+A1: 2014, EN 55035: 2017+A11: 2020),IC (ICES-003: Issue 7:2020),RCM (AS/NZS CISPR 32: 2015)
- SafetyUL (UL 62368-1); CB (IEC 62368-1:2014); CE-LVD (EN 62368-1:2014+A11:2029)
- ChemistryCE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2018)
